Overview

The 1030M MCMA (Multi-Cell Micro-transducer Array) planar speakers from FPS are the ideal choice for in-wall, in-ceiling and some automotive applications and digital POS and signage. The 1030M speakers also work great as external flat panel television and PC speaker configurations.

All MCMA transducers are passive so external amplification is required. The 1030M speakers handle up to 75 watts RMS (150 watts max) at 8 ohms. The 1030M is the second largest MCMA transducer available with almost 93 square inches of surface area the planar effect is very noticeable. FPS builds all their MCMA speakers by embedding an array of voice coils directly into the diaphragm that correspond to an array of powerful neodymium magnets. In the case of the 1030M there are 300 voice coils and 300 corresponding magnets.

Some of the benefits of using the 1030M speaker over a conventional cone speaker with similar specifications are; significantly less mounting depth and back volume is required, MCMA have minimal acoustic feedback, much faster transient response, dipole capability and high resistance to water and temperature.


Features

  • Planar technology
  • Ultra thin and flat
  • Immediate transient response
  • Shallow mounting depth & back volume
  • Focused directional output
  • Dipole capable
  • High resistance to moisture and temperature

Specifications

Input: 75 watts RMS (150 watts max)

SPL @ 1 watt/ .5 meter: 82dB +/- 3dB

Frequency Respopnse: 90Hz - 10kHz

Resonance Frequency: 90Hz +/- 20%

Impedance: 8 ohms

Dimensions Standard: L14.35" W6.475" D.560"

Dimensions Metric: L364.4mm W164.4mm D14.2mm

Weight: 3.02 lbs/ 1380 grams

Stereo/Mono: Mono

Number of Magnets: 300

Number of Voice Coils: 300

Cutout: L13.5" W5.55"/ L341.0mm W141.0mm

Depth: 0.625"/ 15.9mm


Specifications are subject to change at anytime without notice.
